LR24188 1X4 FRAME PANEL WATTAGE SELECTABLE 3CCT
SPECIFICATIONS
  • Item numberLR24188
  • Item description
    LED1X4FRAME/PNL/3WO/3CCT/D
  • Size1x4
  • Shape 1X4
  • Dimensions
    • Length 47.7"
    • Width 11.92"
    • Height 0.5"
  • Finish WHITE
PHOTOMETRIC
  • Color (Temp) CCT SELECTABLE
  • Color (CCT) 3000K/4000K/5000K
  • Lumen 2500/3750/5000
  • Beam Angle 120°
  • CRI 80
ELECTRICAL
  • Power (Wattage) 20/30/40
  • Input Volts 100-277V
  • Rated Lifetime 50000
  • Yearly Cost $3.61
  • Dimmable 0-10V
  • Power Factor >0.95
  • Frequency 50/60Hz
  • Lumen Efficacy 125
  • Operating Temp:
    • Min -4°
    • Max 113°
PACKAGING
  • UPC Barcode 793888411241
  • Master BarCode 10793888411248
  • Master Carton Dimensions:
    • Length 51.18"
    • Width 13"
    • Height 9.05"
    • Weight 5.5kg
  • Case Size 6

LR24188 1X4 FRAME PANEL WATTAGE SELECTABLE 3CCT
